Kärcher ride-on floor scrubber with a steering wheel and seat, grey body, visible brushes underneath.

Scrubber drier

B 110 R Bp Pack Classic +D75

This device requires instruction

Part number: 1.161-433.0

110 l tanks for fresh/dirty water, 75 cm disc brush head, 6 km/h speed
Classic version, 170 Ah AGM batteries, run time of up to 2.5 h, max. 4500 m²/h
Daytime running light, extremely simple to operate, excellent turning circle, only 59 dB(A)

Technical data

Drive type	Battery
Traction drive	Brush motor
Working width, brushes (mm)	750
Working width, vacuuming (mm)	950
Fresh/dirty water tank ( )	110 / 110
Theoretical area performance (m²/h)	4500
Practical area performance (m²/h)	3150
Battery type	Maintenance-free
Battery (V / Ah)	24 / 170
Battery run time (h)	2.5
Voltage (power supply for battery charger) (V)	230
Frequency (power supply for battery charger) (Hz)	50
Driving speed (km/h)	max. 6
Climbing ability (%)	10
Brush speed (rpm)	180
Brush contact pressure (kg / g/cm²)	75 / 40
aisle turning width (cm)	175
Water consumption (l/min)	5
Sound pressure level (dB(A))	59
Weight without accessories (kg)	379
Dimensions (L × W × H) (mm)	1635 x 975 x 1265

Scope of supply

Disc brush, 2 Piece(s)
Battery and charger included
Squeegee, curved
robust aluminium die-cast suction bar

Equipment

Powerful traction drive
Automatic water stop
Solenoid valve
Two-tank system
standard daytime driving light
Type of suction lips: Linatex®
Kärcher colour and operating concept
Kärcher Intelligent Key System (KIK) with over 30 user languages and individual user rights
Home Base fastening possibilities for mop or similar
Easy Operation selector switch

picto easy operation oth 1 EN CI15 110454 CMYK

Product information and benefits

Designed for medium-sized areas, our ride-on scrubber drier B 110 R Classic has a theoretical area performance of 4,500 square metres per hour and is equipped as standard with a 170 Ah AGM battery and a suitable charger. It features 110-litre tanks for fresh and dirty water, the Eco!Mode¹⁾, disc brush technology with a 75-centimetre working width, and a squeegee made of die-cast aluminium. The KIK key system for individual assignment of access rights to machine functions, the multilingual display, the EASY Operation switch, and colour-coded control elements ensure a clear overview and operation. The operator also benefits from daytime running lights to increase passive safety.

Robust squeegee made from die-cast aluminium

With tear-resistant, long-lasting Linatex® suction lips for excellent vacuuming results. Fast and simple replacement of the suction lips. Swerves upon wall contact, thus avoiding damage.

Innovative KIK system

Greater protection against incorrect operation. Lower service costs. Optimum matching to the individual cleaning tasks without overwhelming the user.

Energy-saving eco!efficiency mode

Reduced power consumption. 40% longer runtime per battery charge. Even quieter and thereby ideal for noise-sensitive areas (daytime cleaning, hospitals, hotels, etc.).

Large, colour display

No separate battery charger necessary. Convenient and easy handling. Can be used with various battery types.

Easy handling

Easy handling thanks to logically structured control elements with colour coding. Easier use and shorter learning curve.
