Kärcher high-pressure cleaner with grey body, large wheels, and attached hose, positioned on a white background.

Awards and exclusive range

High pressure cleaner

HD 10/25-4 S

This device requires instruction

Part number: 1.286-954.0

Top quality, ergonomic handling and maximum performance
Brass cylinder head, stainless steel piston, pressure cut-off, LED display
10-metre-long high-pressure hose, EASY!Force Advanced, 1050 mm spray lance, power nozzle

Technical data

Number of current phases (Ph)	3
Voltage (V)	376 - 424
Frequency (Hz)	50
Flow Rate (l/h)	500 - 1000
Water feed temperature (°C)	60
Operating pressure (bar)	80 - 250
Max. Pressure (bar)	280
Power rating (kW)	8.8
Power cable (m)	5
Nozzle size	047
Water inlet	1″
Colour	anthracite
Weight (with accessories) (kg)	69.8
Weight incl. packaging (kg)	78.1
Dimensions (L × W × H) (mm)	607 x 518 x 1063

Scope of supply

Spray gun, EASY!Force Advanced
High-pressure hose length, 10 m
High-pressure hose type, Premium quality
High-pressure hose specification, DN 8, 315 bar
Spray lance, 1050 mm
Power nozzle
Servo Control

Equipment

4-pole three-phase motor with air and water cooling
Three piston axial pump: with stainless steel pistons
Pressure cut-off
Integrated fine mesh water filter
Motor protection electronics with LED display
Sight glass for oil level
Brass water inlet fitting

Recommended maximum duration of use in hours/day.

Trigger gun regulation of pressure and water flow.

High-pressure trigger gun with zero holding force for fatigue-free operation.

Robust, long-lasting quick-release lock: five times faster than screwing.

Product information and benefits

The cold water high-pressure cleaner HD 10/25-4 S is equipped with the EASY!Force Advanced gun and a rotatable 1050-millimeter stainless steel lance. Pressure and water volume can be regulated with the Servo-Control regulator on the gun or lance. The device has assistance systems and an LED status display. A swashplate pump with stainless steel pistons and a brass cylinder head as well as a 4-pole motor with water and air cooling are installed. The chassis consists of aluminum frame carriers and is suitable for crane loading. The motor and pump unit are installed vertically (upright concept). A kangaroo pocket and adjustable hooks serve for accessory storage.

HD super class construction app 02 CI20502x502

Compact upright design concept based on vertical arrangement of motor and pump unit

Small footprint and space-saving proportions. Easy to manoeuvre and transport. Maximum stability ensures a stable footing for the machine.

4-pole low-speed motor with air-water cooling system, solid pump with stainless steel pistons and brass cylinder head

Long service life and low maintenance costs. High performance With suction feature and up to 60 °C water temperature.

Intelligently designed service concept facilitates quick operations on site

Convenient oil fill level display and oil drain hole integrated in the chassis. Modular construction, comprising pump, motor and control cabinet.

Assistance systems and LED status display

Integrated electronics system for machine monitoring. Automatic switch-off in case of low voltage range or overvoltage. Switches off in case of leaks or phase failure.

Wide-ranging accessories with EASY!Lock

Pressure and water volume can be adjusted on the Servo Control controller positioned between the lance and trigger gun. EASY!Force Advanced for fatigue-free work without any holding force. Rotating 1050 mm stainless steel lance.

Extensive range of accessories and attachment kits

Stowage compartment. Adjustable hooks, e.g. for storing second lance or electric cable. Storage for high pressure hose.

Product safety and documents

Applications and videos

Application areas

Cleaning tractors, machines and implements in agriculture
Cleaning machines and equipment on the building site, such as cement mixers, scaffolding, wheel loaders, diggers or concrete pumps
Cleaning production machinery in industry, such as in paint shops, in food production or in the manufacturing sector
Cleaning vehicles in transport sector, such as trucks, ships, aeroplanes or buses
Cleaning communal spaces such as public squares, driveways, fountains or car parks
