High pressure cleaner

HDS 10/21-4 MXA

This device requires instruction

Part number: 1.071-938.0

eco!efficiency mode, water-cooled 4-pole electric motor with axial pump
Automatic hose reel with 20-metre-long Ultra Guard hose with Teflon® coating
EASY!Force Advanced with servo control controller, 2 detergent tanks, descaler

Technical data

Number of current phases (Ph)	3
Voltage (V)	400
Frequency (Hz)	50
Flow Rate (l/h)	500 - 1000
Operating pressure (bar / MPa)	30 - 210 / 3 - 21
Max. Pressure (bar)	250
Temperature (supply 12°C) (°C)	min. 80 - max. 155
Power rating (kW)	8
Consumption of fuel oil at full load (kg/h)	7.3
Heating oil consumption, eco!efficiency (kg/h)	5.8
Power cable (m)	5
Fuel tank (l)	25
Weight (with accessories) (kg)	172.6
Weight incl. packaging (kg)	184.8
Dimensions (L × W × H) (mm)	1330 x 750 x 1210

Scope of supply

Spray gun: EASY!Force Advanced
High-pressure hose length: 20m
High-pressure hose specification: DN 8, 315 bar
Spray lance: 1050mm
Power nozzle
Servo Control

Equipment

Detergent function: 20 + 10 l tank
integrated automatic hose reel
ANTI!Twist
Tanks for detergent, calcification protection and fuel that can be filled from the outside
Control bar with display light
Pressure cut-off
Pole reversing plug (three-phase)
2 Detergent tanks
Dry running protection

Recommended maximum duration of use in hours/day.

picto automatic hose reel CMYK oth 01 EN CI15

Trigger gun regulation of pressure and water flow.

High-pressure trigger gun with zero holding force for fatigue-free operation.

Robust, long-lasting quick-release lock: five times faster than screwing.

Switchable cleaning agent dosing system.

Weeding with our weed remover and hot water high-pressure cleaners without chemicals.

picto certified virus disinfection CMYK oth 01 EN CI20

Product information and benefits

As Kärcher's most powerful hot water high-pressure cleaner in the middle class, the HDS 10/21-4 MXA with automatic hose reel and integrated Ultra Guard HP hose is impressive in all respects. The hose reel allows the 20-metre-long, Teflon-coated hose to be wound and unwound at an angle of up to 45° and also shortens the usual set-up time by just over 50 per cent. In addition, the robust 3-piston axial pump with ceramic piston, the low-speed, water-cooled, 4-pole electric motor, optimised burner engineering and the economical eco!efficiency mode ensure maximum performance and economical operation. Users also benefit from intelligent ergonomics thanks to the energy-saving EASY!Force Advanced HP trigger gun with 1050 millimetre spray lance and servo control, as well as the simple 1-switch operation and the many options for accessory storage. The machine, which is extremely easy to maintain, also stands out from the crowd with its 2 detergent tanks, patented nozzle technology, proven safety technology and time-saving EASY!Lock quick-release fasteners as standard.
