Kärcher grey and black industrial cleaning machine with control panel and yellow dials.

Awards and exclusive range

High pressure cleaner

HDS 10/21 -4 St EU-I

This device requires instruction

Part number: 1.699-931.0

4-pole air-cooled motor and robust crankshaft pump with ceramic piston
Easy installation, operation and maintenance of the machine

Technical data

Number of current phases (Ph)	3
Voltage (V)	400
Frequency (Hz)	50
Flow Rate (l/h)	500 - 1000
Operating pressure (bar)	210
Max. Pressure (bar)	235
Temperature (supply 12°C) (°C)	max. 80
Water feed temperature (°C)	max. 30
Power rating (kW)	8
Consumption of fuel oil at full load (kg/h)	6.5
Heat energy (kW)	77
Power cable (m)	5
Water inlet	1″
Mobility	stationary
Fuse protection (A)	25
Weight (with accessories) (kg)	160
Weight incl. packaging (kg)	170
Dimensions (L × W × H) (mm)	1142 x 578 x 790

Scope of supply

Flame monitor
Prepared for Servo Control
Prepared for remote operation
Power nozzle
Detergent function: Suction

Equipment

Oil dipstick
Sight glass for oil level
Pre-equipped for a detergent inlet
RM1 dosage
Dry running protection
Large fine mesh water filter
Storage tank with float valve
Crankshaft pump with ceramic pistons
Water-cooled motor
Frame and cover: Steel, powder-coated

Recommended maximum duration of use in hours/day.

Trigger gun regulation of pressure and water flow.

Robust, long-lasting quick-release lock: five times faster than screwing.

Switchable cleaning agent dosing system.

Product information and benefits

The HDS 10/21-4 St is a stationary hot water high-pressure cleaner with an oil burner that delivers extra high pressure: up to 210 bar of pressure makes light work of even stubborn dirt. The 4-pole, low-speed electric motor generates high power for demanding continuous use. The robust crankshaft pump with brass cylinder head provides up to 1000 litres of water per hour. The water storage tank has integrated limescale protection and a water filter to protect the pump. The detergent is taken up and dosed with precision by a valve. An empty indicator shows when detergent is running out. Electronic monitoring of the oil burner and the overall technology ensures a high level of operational safety. An intuitive rotary switch or optional remote control make operation simple, and service and maintenance tasks are also designed to be user-friendly. With a wide range of accessories available, the HDS 10/21-4 St can be customised to suit a wide variety of cleaning tasks. The machine can be supplemented with a pressure gauge and hour counter, a second detergent dosing unit and a pressure relief system.
