Kärcher professional trailer-mounted cleaning unit with grey casing and tow bar, featuring wheels and hitch.

Awards and exclusive range

HDS Trailer

HDS 13/35 De Tr1

This device requires instruction

Part number: 1.524-521.204

Automatic speed reduction
Speed regulation
Stationary and mobile versions available

Technical data

Drive type	Diesel
Motor manufacturer	Yanmar
Motor rating (kW / hp)	19 / 26
Flow Rate (l/h)	650 - 1300
Pressure (bar / MPa)	100 - 350 / 10 - 35
Heating oil consumption, eco!efficiency (kg/h)	9.3
Weight (with accessories) (kg)	945
Dimensions (L × W × H) (mm)	3635 x 1747 x 1730

Scope of supply

Spray gun: Industry
High-pressure hose: 30m
Spray lance: 700mm
Power nozzle

Equipment

Pressure adjustment over speed regulation

Recommended maximum duration of use in hours/day.

Weeding with our weed remover and hot water high-pressure cleaners without chemicals.

Product information and benefits

The real trump card of the HDS 13/35 is its mobility. The hot water pressure washer generates pressures of 350 bar, works entirely independently of any power source and is therefore completely flexible in terms of its application – for example on construction sites, in industry and in the municipal sector. The freely configurable cleaning machine is an absolute all-rounder thanks to its reliability, efficiency, ease of servicing and operating comfort.

Maximum efficiency

Highly efficient burner technology. Heat recovery through use of waste heat from the engine. Environmentally-friendly operation and low operating costs thanks to Kärcher's eco!efficiency mode.

Easy operation

The machine is easy to operate using a central selector switch. Two optional hose reels in operating area allow easy set-up and dismantling. Safe and ample storage options for protective equipment, accessories and detergents.

Self-sufficient application

Large 500 l water tank for up to 30-minute cleaning applications with full water performance. 100-litre diesel tank: ideal for long periods of use. Powerful Yanmar diesel engines allow the machine to be used independently of any power source.

High flexibility

Thanks to its configurability, each trailer can be custom-made according to customer requests. Skid and Cab versions make different uses possible: mobile or stationary.

Service-friendly

A large hood enables service staff to access the internal components more easily. Sophisticated service software for rapid fault diagnosis during servicing. Tried-and-tested high-quality Kärcher components guarantee a long lifetime.

Reliability

Includes: Water softening system to protect the heating coil against calcification. Numerous safety functions protect the HDS trailer against damage in the case of an error. Integrated frost protection mode to protect all components in cold exterior temperatures.
