Implement carriers

Holder S 75

Name: Holder S 75
Brand: Kärcher
SKU: 8.343-703.0

This device requires instruction

Part number: 8.343-703.0

Robust, strong and all-terrain: the multifunctional Holder S 75 implement carrier is a real powerhouse – the ideal municipal vehicle for year-round use under the toughest conditions.

Make an enquiry

Technical data

Drive	Diesel
Traction drive	All-wheel drive
Motor manufacturer	Deutz
Motor rating (kW)	55
Displacement (cm³)	3621
Cylinder	4
Exhaust emissions standard	STAGE V
Fuel tank (l)	84
Driving speed (km/h)	- 40
Working speed (km/h)	- 20
Wheelbase (mm)	1827
Permissible total weight (kg)	5500
Weight without accessories (kg)	3500
Weight incl. packaging (kg)	3500
Dimensions (L × W × H) (mm)	4000 x 1600 x 2300

Equipment

Particle filter
Air conditioning
Heater
Rotating warning beacon
Year-round use

AGR certificate municipal sweeper CMYK oth 02 EN CI20

Product information and benefits

Whether it's winter service or green maintenance and irrigation, the new Holder S 75 performs a wide range of tasks of the highest quality for you. Its articulated steering guarantees maximum manoeuvrability even in narrow areas or on pavements. This enables agile, precise and directionally stable working with perfect work results. The permanent all-wheel drive distributes the power of the 75 hp engine optimally to all four wheels and ensures excellent traction. With a clearance width of 1.31 metres (depending on tyres), the municipal implement carrier can easily reach every nook of its area of operation 365 days a year. Even the toughest operations can be easily controlled from the comfort cab.

High variability for vehicle types, construction and expansion options

Flexible use and large selection of powerful implements. Quick-change system enables 1 person to change implements without the need for any tools. Two standard attachment areas (front/rear) and a 3rd attachment area for articulated implements.

Ergonomic and comfortable cab

Optimal room climate in all weathers with air-conditioning, heating, and rotating air nozzles. 360° panoramic view for unobstructed view of working area and safe manoeuvring. Ergonomically arranged working area.

Easy service access

Daily service work is possible without removal of implements. Hydraulically tiltable engine compartment cover allows tilting with articulated machine. Swivel-mounted or foldable side parts on right and left sides.
