Dry ice blaster

IB 10/8 L2P

This device requires instruction

Part number: 1.574-200.0

With integrated dry-ice production
Compact, mobile design and easy operation
Low compressed air consumption for use of workshop compressors

Technical data

Power rating (kW)	1
Housing/Frame	Plastic rotation body
Tested by	CE
Cable length (m)	5.5
Air pressure (bar / MPa)	0.7 - 10 / 0.07 - 1
Quality of air	Dry & oil-free
Air flow (m³/min)	0.07 - 0.8
Sound pressure level (dB(A))	95
Dry ice pellets (diameter) (mm)	2.5
Dry ice consumption (kg/h)	2 - 8
Liquid CO₂ consumption (kg/h)	20 - 60
Number of current phases (Ph)	1
Frequency (Hz)	50 - 60
Voltage (V)	220 - 230
Weight without accessories (kg)	92
Weight (with accessories) (kg)	103.6
Dimensions (L × W × H) (mm)	870 x 450 x 970

Scope of supply

Flat jet nozzle, short
Blasting hose with electrical control wire and quick couplers
Blasting gun (ergonomic & save)

Equipment

Switch for "air only" or "ice and air"
Electronic control unit

Product information and benefits

Spontaneous cleaning work with dry ice blasters in machine or vehicle maintenance, for cleaning in the manufacturing process or for vehicle conditioning were hardly conceivable up to now as the dry ice logistics behind the scenes was too costly for short-term applications. This is now possible with the IB 10/8 L2P, the world's first dry ice blaster with integrated dry ice production made from liquid CO₂. Thanks to an innovative process, dry ice pellets are made from liquid CO₂ when necessary – L2P stands for "Liquid-to-Pellet". As liquid CO₂ can be stored in gas cylinders for practically an unlimited amount of time, the usual time-consuming dry ice logistics are avoided. The very low compressed air consumption of the machine also significantly reduces the infrastructure requirements. At the same time, the advantages of the Kärcher dry ice technology are fully retained. The IB 10/8 L2P cleans very gently – also for complex contours such as grooves, bearings or grooves and in the case of heavy contamination such as burnt-on encrustations. Abrasive residues are reliably avoided.

Ergonomic blasting gun

Quick and easy nozzle change thanks to quick-release couplings. With integrated lighting. Ice on/off switch directly on the trigger gun.

Easy and intuitive operation

Jet pressure, operating hours, service time shown on the display. Dry-ice quantity can be adjusted with a button. Integrated status display and assistance systems, e.g. for pressure monitoring.

Safe dry-ice blasting

CO₂ is discharged via exhaust hose. Safe handling, no contact with the dry-ice pellets. Self-locking gun trigger.

Compact, mobile design

Wheels and handles allow mobility and safe transport. Separate storage possibility for all components. Integrated home base.
