Name: IVM 60/ 36-3 H ACD
Brand: Kärcher
SKU: 9.990-524.0
Price: 5389.99 GBP
Availability: InStock

Technical data

Number of current phases (Ph)	1
Voltage (V)	220 - 240
Frequency (Hz)	50 - 60
Air flow (l/s / m³/h)	117 / 420
Vacuum (mbar / kPa)	201 / 20.1
Container capacity (l)	60
Container material	Stainless steel
Rated input power (kW)	3.6
Vacuuming type	Electric
Sound pressure level (dB(A))	up to 79
Cable length (m)	7.5
Main filter dust class	M
Filter area for main filter (m²)	2
Secondary filter dust class	H
Filter area for secondary filter (m²)	3.5
Weight without accessories (kg)	67
Weight incl. packaging (kg)	67
Dimensions (L × W × H) (mm)	1020 x 680 x 1670

Equipment

Main filter: Star filter
Secondary filter: Cartridge filter
Accessories included with machine: no

Recommended maximum duration of use in hours/day.

Product information and benefits

Mid-class industrial vacuum cleaner IVM 60/36-3 H ACD of dust class H for vacuuming combustible solids outside ATEX zones. The vacuum cleaner operates with 3 individually controllable motors in single-phase operation; the 60-litre collection container enables the intake of large quantities. In addition to the H-filter, the machine features a dust class M PTFE star filter and the Pull and Clean filter cleaning system for uninterrupted cleaning during operation. Components such as the acid-resistant stainless steel collection and filter container as well as the steel chassis are designed for continuous industrial use. Large wheels facilitate transport to the site of use.

ACD – Applied for Combustible Dust

For the safe and economical vacuuming of combustible dusts. Conforms to the IEC 60335-2-69 standard.

Dust class H

Overall device certified according to DIN EN 60335-2-69 for dust class H. For safely picking up hazardous dusts (OEL < 0.1 mg/m³) and flammable solids.

Manual pull-and-clean filter cleaning

Filter is cleaned in a single step during operation. Low-wear dedusting by means of air reversal.

Fitted with three blower motors

Three powerful fans for impressive cleaning performance. Individually controlled motors mean the suction power can be adjusted as required.

Features large star filter and additional cartridge filter

For safely picking up solids and dusts up to dust class H. Two-step filter system and optimum separation degree for maximum safety.
