Kärcher professional steam cleaner with wheels, control panel, and hose attachment.

Dry ice blaster

IB 15/120

This device requires instruction

Order number: 1.574-104.0

Engineered for continuous commercial and industrial use
Oil and water separator
For the most intensive jobs

Technical data

Connected load (kW)	0.6
Compressed air connection	Claw coupling (DIN 3238)
Casing / frame	Stainless steel (1.4301)
Cable length (m)	7
Air pressure (bar / MPa)	2 - 16 / 0.2 - 1.6
Air quality	Dry & oil-free
Air flow (m³/min)	2 - 12
Sound pressure level (dB(A))	125
Dry ice capacity (kg)	40
Dry ice pellets (diameter) (mm)	3
Dry ice consumption (kg/h)	30 - 120
Number of current phases (Ph)	1
Frequency (Hz)	50 - 60
Voltage (V)	220 - 240
Weight without accessories (kg)	91
Weight (with accessories) (kg)	101.5
Dimensions (L × W × H) (mm)	1000 x 800 x 1300

Scope of supply

Nozzle case with foam insert
Grease for nozzle threads
Flat jet nozzle
Flat jet nozzle insert, 8 mm
Open-end wrench (for changing nozzles), 2 Piece(s)
Round spray nozzle, XL, long
Spray hose with electrical control cable and quick coupling
Jet gun (ergonomic and safe)

Equipment

"Air only" or "Air and ice" switch on the trigger gun
Electronic control unit
Includes ground strap coil
Oil and water separator

Product information and benefits

The Ice Blaster IB 15/120 is powerful, robust and extremely reliable. The intelligent, detailed solutions such as case holder, ice emptying, retaining bracket and storage compartments also contribute to its positive overall impression, increase operating comfort and make dry ice cleaning more enjoyable. And from a technical point of view, the solution lies in the detail, which is why we have significantly improved the air streaming in the machine, hose, trigger gun and nozzle. The result: outstanding cleaning performance. In spite of its size, the IB 15/120 is very mobile and can be carried easily by one person, for example over stairs. In short: dry ice blasting at its best!

Nozzle case holder

Blasting spray nozzles and tools are always at hand on the machine. The nozzle case is attached to the side of the machine to protect it from dirt.

Outstanding mobility

Optimum balancing of the device for convenient manoeuvring on uneven terrain. Bars at the front and rear of the device make it easy to negotiate stairs.

Automatic residual ice discharge

The ability to empty the residual ice tank at the touch of a button prevents the device from icing up once work is complete. The machine does not freeze.

GFRP dry ice container

Optimum insulation of the dry ice. No condensation. No icing up of the machine.

Efficient airflow in the device

The dry ice is transported from the device to the nozzle without any damage. Ultimate cleaning performance at the nozzle.

Integrated ground strap coil

Easy earthing of the object being blasted. Protection from arcing from the user to the object. Improved jet convenience.

Integrated oil and water separator

No icing up of the device.

Refined trigger gun holder

The trigger gun is always perfectly stored. Ideal position (e.g., for changing the nozzles).

IB 15/120

Technical data

Product information and benefits

Nozzle case holder

Outstanding mobility

Automatic residual ice discharge

GFRP dry ice container

Efficient airflow in the device

Integrated ground strap coil

Integrated oil and water separator

Refined trigger gun holder

Integrated storage compartment for nozzles and tools
