Kärcher industrial vacuum cleaner with a stainless steel body, control panel, and wheels for mobility.

Industrial vacuums

IVM 40/12-1 H Z22

This device requires instruction

Order number: 9.990-266.0

Suitable for use in ATEX zone 22
Low-wear EC turbine

Technical data

Voltage (V)	220 - 240
Frequency (Hz)	50 - 60
Air flow (l/s / m³/h)	43.8 / 158
Vacuum (mbar / kPa)	249 / 24.9
Container capacity (l)	40
Container material	Stainless steel
Rated input power (kW)	1.2
Vacuuming type	Electric
Sound pressure level (dB(A))	73
Cable length (m)	10
Main filter dust class	M
Filter area for main filter (m²)	1.6
Secondary filter dust class	H
Filter area for secondary filter (m²)	1.6
Weight without accessories (kg)	51
Weight incl. packaging (kg)	51
Dimensions (L × W × H) (mm)	645 x 655 x 1140

Equipment

Main filter: Star filter
Secondary filter: Cartridge filter
Accessories included in the scope of delivery: no

Machine with certified explosion protection.

Recommended maximum duration of use in hours/day.

Machines with certification for Zone 22.

Product information and benefits

For universal vacuuming of fine and coarse solids in ATEX zone 22: the single-motor, explosion-protected mid-class industrial vacuum cleaner IVM 40/12-1 H Z22 equipped with an EC turbine. The device operates in single-phase operation, has a compact design, is mobile, and is built for applications where special safety regulations must be observed. The large dust class M star filter can be cleaned during operation using the Pull and Clean filter cleaning system. In addition, the vacuum cleaner is equipped with a downstream certified H cartridge filter with filter detection and is certified to dust class H. The filter container and collection container are made of acid-resistant stainless steel, while the chassis is made of steel.

Certified for ATEX Zone 22

Explosion-proof industrial vacuum for safe vacuuming in ATEX Zone 22.

Dust class H

Overall device certified according to DIN EN 60335-2-69 for dust class H. For safely picking up solids and dusts up to dust class H.

Low-wear EC turbine

Brushless design for low-wear operation. Suitable for three-shift operation thanks to a minimum service life of 5000 hours.

Manual pull-and-clean filter cleaning

Filter is cleaned in a single step during operation. Low-wear dedusting by means of air reversal.

Features extra-large star filter and additional cartridge filter

For safely picking up solids and dusts up to dust class H. Maximum safety thanks to 2-stage filter system with optimum separation degree.
