Kärcher ride-on sweeper with grey body, steering wheel, large brush, and amber light on top.

Vacuum sweeper

KM 120/250 R D Classic

This device requires instruction

Order number: 1.186-000.0

Sweeper with internal combustion engine, high container emptying
1200 mm working width, 7200 m²/h area performance, 250 l container volume
Pocket filter, side brush on the right, flashing beacon

Technical data

Drive type	Diesel
Traction drive	Four-stroke engine
Motor manufacturer	Yanmar
Drive – Power (kW)	15.8
Max. area performance (m²/h)	10800
Working width (mm)	900
Working width with 1 side brush (mm)	1200
Working width with 2 side brushes (mm)	1500
Waste container (l)	250
Climbing ability (%)	18
Working speed (km/h)	9
Filter area (m²)	6
Weight (with accessories) (kg)	883
Weight, ready for operation (kg)	800
Weight incl. packaging (kg)	883
Dimensions (L × W × H) (mm)	2082 x 1250 x 1450

Scope of supply

Pocket filter
Wheels, solid rubber

Equipment

Manual filter cleaning
Adjustable main sweeper roller
Main sweeper roller, floating
Power steering
Suction volume regulation
Dustpan principle
Traction drive, forwards
Traction drive, reverse
Suction
Hydr. high dump
Outdoor use
Elapsed time counter
Sweeping function, can be switched off
Side brush, automatically swings out

Product information and benefits

Our powerful KM 120/250 R D Classic industrial sweeper is especially suited to challenging terrain. The robust design, large waste container and a resistant pocket filter with vibration motor make it the ideal choice for harsh applications in extremely dusty environments, such as those in the construction and metalworking industry as well as in foundries. The diesel-powered machine with fully hydraulic rear-wheel drive and sweeping system is especially designed for outside areas and also impresses with its user-, maintenance- and service-friendliness. Thanks to the integrated Flexible Footprint System, the brushes adapt perfectly to the ground surface and, together with the dustpan principle, ensure excellent cleaning results with fine as well as coarse waste. Lastly, in combination with hydraulic high container emptying, it ensures the convenient disposal of the dirt removed.

Robust design of the machine for safe work

Permits applications in extreme external conditions. Leads to longer service life of components and machine. Standard flashing beacon increases safety for user and environment.

Large-area pocket filter with vibration motor

The large filter area guarantees dust-free work. Effective filter cleaning by means of vibrating motor. Suitable for particularly large quantities of dust.

Simple operation, maintenance and servicing

Simple technology with tried-and-tested components. Easy access to engine compartment permits fast, simple servicing and maintenance. Main sweeper roller and pocket filter can be replaced without tools.

Dustpan principle

Guarantees good cleaning results also with fine waste. Effortless pick-up of coarse waste. Low dust production.

Flexible Footprint System

Excellent sweeping results. Low brush wear. Optimal adaptation of brushes to different ground/surfaces.

Hydraulic high container emptying

Simple and safe emptying of waste. Convenient tipping up to 1.42 metres.

Hydraulic rear-wheel drive with solid rubber tyres

High agility and simple handling also in confined spaces. Allows safe passage over pointed objects made from metal or glass. Solid rubber tyres rule out tyres going flat.
