Black Mercedes truck being washed in an automated car wash system, with brushes and water jets cleaning the vehicle.

Commercial vehicle washes

TB

This device requires instruction

Order number: 1.534-052.2

Flexible adaptation to any location
Four adjustable wash heights, hot-dip galvanised steel framework
Patented side brush suspension system

Technical data

Wash bay requirement (mm)	2800 x 4800 x 5990
Wash height (mm)	3600 / 4250 / 4600 / 5050
Machine height (mm)	4539 / 5189 / 5539 / 5989
Machine height with splash guard (mm)	4597 / 5247 / 5597 / 6047
System width with Splash Guard (mm)	5000
System width with rotating side brushes (mm)	4830
Fresh water connection volume (l/min)	100
Fresh water connection pressure (bar)	4 / 6
Power input (kW)	5.3
Number of current phases (Ph)	3
Voltage (V)	400
Frequency (Hz)	50
Software updates available until	2031-01-01

Equipment

Individual brush equipment
Flexible control panel

Equipment features of the machine are individually configurable.

Product information and benefits

The commercial vehicle wash system impresses with maximum reliability, flexibility and optimal cleaning results. It is suitable for a wide variety of locations and can be individually adapted to the specific conditions on site. Four adjustable wash heights, which can be reduced by up to 300 millimetres in 100 mm increments, and an adjustable system width (reduced by 100 mm on each side) enable precise configuration depending on the vehicle type and space available. Even vehicles with convex contours are given a thorough clean thanks to powerful high-pressure spinners. The patented side brush suspension system moves freely in all directions and guarantees high reliability – even under demanding conditions. Belt and direct drives ensure low-maintenance operation without the need for lubrication. The system is therefore the ideal solution for forwarding agencies, bus operators and anyone who needs powerful and adaptable commercial vehicle cleaning.

Patented side brush suspension system

Brushes can move freely in all directions. No bending of the shafts. Contact pressure is individually adapted to the vehicle for optimal washing results.

Control unit with integrated touchscreen

Flexible configuration of all parameters. Customised adaptation to any vehicle fleet.

Flexible adaptation to any location

Four different wash heights, which can be reduced by up to 300 mm in increments of 100 mm. The system width can be reduced by 100 mm on each side.
