Kärcher high-pressure cleaner with hose reel and handle, grey and yellow accents, on wheels.

Awards and exclusive range

High-pressure cleaner

HD 10/25-4 SXA Plus

Order number: 1.286-955.0

Top quality, ergonomic handling and maximum performance
Brass cylinder head, stainless steel piston, pressure cut-off, LED display
20-metre-long high-pressure hose, EASY!Force Advanced, 1050 mm spray lance, Vibrasoft rotary nozzle

Technical data

Number of current phases (Ph)	3
Voltage (V)	376 - 424
Frequency (Hz)	50
Flow rate (l/h)	500 - 1000
Inlet temperature (°C)	60
Working pressure (bar)	80 - 250
Max. pressure (bar)	280
Connected load (kW)	8.8
Power cable (m)	5
Nozzle size	047
Water inlet	1″
Colour	anthracite
Weight (with accessories) (kg)	81.9
Weight incl. packaging (kg)	90.2
Dimensions (L × W × H) (mm)	607 x 518 x 1063

Scope of supply

Spray gun: EASY!Force Advanced
High-pressure hose length: 20m
High-pressure hose type: Ultra Guard
High-pressure hose specification: DN 8, 315 bar
Spray lance: 1050mm
Power nozzle
Dirt blaster
Servo Control

Equipment

4-pole three-phase motor with air and water cooling
3-piston axial pump: with stainless steel pistons
Pressure cut-off
Integrated water fine filter
Motor protection electronics with LED display
Sight glass for oil level
Brass water inlet

Recommended maximum duration of use in hours/day.

picto automatic hose reel CMYK oth 01 EN CI15

picto vibrasoft rotary jet CMYK oth 01 EN CI15

picto ultra guard hose CMYK oth 01 EN CI15

Regulierung von Druck und Wassermenge an der Pistole.

High-pressure trigger gun with zero holding force for fatigue-free operation.

Schlauch mit frei drehbar gelagerten Anschlüssen.

Robust, long-lasting quick-release lock: five times faster than screwing.

Product information and benefits

The HD 10/25-4 SXA Plus cold water high-pressure cleaner is designed with the very best quality and ergonomics in mind. The EASY!Force Advanced high-pressure gun eradicates any holding forces. Pressure and water volume can be adjusted on the Servo Control controller positioned between the lance and trigger gun. This means the pressure can be adjusted to suit delicate surfaces – without having to change the nozzle or make adjustments on the machine itself. The Vibrasoft rotary nozzle dampens noise and vibrations. Assistance systems and LED status display provide clear information. The Super Class machine stands out from the crowd for its exquisite workmanship and finest quality materials. At its heart lies a hard-wearing wobble pump with stainless steel pistons and brass cylinder head. The 4-pole low-speed motor with air-water cooling system is powerful and built to last. Integrated aluminium frame carriers form a lightweight chassis, suitable for crane loading. The upright construction style with vertical motor and pump unit keeps the machine compact and portable. It also features an Ultra Guard high-pressure hose with a Teflon® coating and ample built-in storage for accessories, as well as an automatic hose reel for winding and unwinding at up to 45 ° – even under pressure.

Automatic hose reel

Automatic winding and unwinding up to an angle of 45 °, even under pressure. Scratch-resistant and smooth Ultra Guard HD hose with Teflon® coating. Set-up times up to twice as fast.

Compact upright design concept based on vertical arrangement of motor and pump unit

Small footprint and space-saving proportions. Easy to manoeuvre and transport. Maximum stability ensures a stable footing for the machine.

4-pole low-speed motor with air-water cooling system, robust pump with stainless steel pistons and brass cylinder head

Long service life and low maintenance costs. High performance and high efficiency. With suction feature and up to 60 °C water temperature.

HD super class agriculture app 55 CI20502x502

Ergonomic Vibrasoft Dirt Blaster

Reduces vibrations by up to 30%. Reduces volume and noise level. Rotary nozzle takes the hard work out of extensive cleaning tasks.

Intelligently designed service concept facilitates quick operations on site

Swivelling pump head. Convenient oil fill level display and oil drain hole integrated in the chassis. Modular construction, comprising pump, motor and control cabinet.

Assistance systems and LED status display

Integrated electronics system for machine monitoring. Automatic shutoff in event of low voltage range or overvoltage. Switches off in case of leaks or phase failure.

Wide-ranging accessories with EASY!Lock

Pressure and water volume can be adjusted on the Servo Control controller positioned between the lance and trigger gun. EASY!Force Advanced for fatigue-free work without any holding force. Rotating 1050 mm stainless steel lance.

Multiple storage spaces for accessories integrated into the machine

Stowage compartment. Adjustable hooks, e.g. for storing second lance or electric cable. Storage for high pressure hose.

Product safety and documents

Applications and videos

Application areas

Cleaning tractors, machines and implements in agriculture
Cleaning machines and equipment on the building site, such as cement mixers, scaffolding, wheel loaders, diggers or concrete pumps
Cleaning production machinery in industry, such as in paint shops, in food production or in the manufacturing sector
Cleaning vehicles in transport sector, such as trucks, ships, aeroplanes or buses
Cleaning communal spaces such as public squares, driveways, fountains or car parks
