Grey Kärcher high-pressure cleaner with wheels, hose reel, and control panel, viewed from the rear angle.

Awards and exclusive range

High-pressure cleaner

HDS 8/18-4 C

This device requires instruction

Order number: 1.174-918.0

Compact and powerful, water-cooled 4-pole motor with axial pump
10-metre-long high-pressure hose, modular electronics like in M/S class, storage compartment for accessories
EASY!Force Advanced with servo control controller, detergent tank, steam stage

Technical data

Number of current phases (Ph)	3
Voltage (V)	400
Frequency (Hz)	50
Flow rate (l/h)	300 - 800
Working pressure (bar / MPa)	30 - 180 / 3 - 18
Max. pressure (bar)	220
Temperature (for supply 12 °C) (°C)	min. 80 - max. 155
Connected load (kW)	6
Consumption of fuel oil at full load (kg/h)	5.2
Consumption of heating oil in eco!efficiency mode (kg/h)	4.2
Power cable (m)	5
Nozzle size	025
Fuel tank (l)	15
Weight (with accessories) (kg)	119.4
Weight incl. packaging (kg)	131.2
Dimensions (L × W × H) (mm)	1066 x 650 x 920

Scope of supply

Spray gun: EASY!Force Advanced
Spray lance: 1050mm
Power nozzle
Servo Control

Equipment

High-pressure hose length
Soft Damping System (SDS)
Pressure cut-off

Recommended maximum duration of use in hours/day.

Regulierung von Druck und Wassermenge an der Pistole.

High-pressure trigger gun with zero holding force for fatigue-free operation.

Schlauch mit frei drehbar gelagerten Anschlüssen.

Robust, long-lasting quick-release lock: five times faster than screwing.

Machine that is suitable for operation with biodiesel.

The machine can also be operated with synthetic diesel fuels, so-called e-fuels.

Weeding with our weed remover and hot water high-pressure cleaners without chemicals.

picto certified virus disinfection CMYK oth 01 EN CI20

Product information and benefits

The most powerful 3-phase hot water high-pressure cleaner in the compact class: the HDS 8/18-4 C with eco!efficiency and steam stage impresses with its ergonomics and user-friendliness. Its powerful 4-pole motor is water-cooled. A robust axial pump with three ceramic pistons builds up high pressure. The EASY!Force Advanced high-pressure gun with servo control for easy adjustment of pressure and water flow, patented nozzle technology and EASY!Lock quick-release fasteners makes for ergonomic work. The Soft Damping System (SDS) reduces vibrations. The hot water technology effectively breaks up even lubricants and reduces the use of detergents, which are precisely dosed from a 15.5-litre tank. The maintenance-friendly HDS 8/18-4 C is designed for daily use under hard conditions. The descaling option, a water filter and a safety valve protect the technology. A robust chassis protects against impacts, while large wheels and a steering roller/castor offer high manoeuvrability. There are integrated storage possibilities for accessories.

High efficiency

eco!efficiency mode – economical and environmentally friendly, even during longer periods of use. Reduces fuel consumption and CO₂ emissions by 20%.

Wide-ranging accessories with EASY!Lock

EASY!Force Advanced for fatigue-free work without any holding force. Pressure and water volume can be adjusted on the Servo Control controller positioned between the lance and trigger gun. Rotating 1050 mm stainless steel lance.

Operational safety

Easy-to-access water filter protects the pump against dirt particles in the water. Safety valves, water shortage and fuel protection ensure the availability of the machine.

Reliability

Water softening system to protect the heating coil against calcification damage. The Soft Damping System (SDS) compensates for vibrations and pressure peaks in the high-pressure system.

Multiple storage spaces for accessories integrated into the machine

Storage hooks for power cable and high-pressure hose. Integrated nozzle storage. Integrated lance holder for transport.

Detergent dosing unit

Precise detergent dosing unit with rinse function. Large tank opening with filling chute.

Mobility concept

"Jogger" design with large rubber wheels and steering roller. Integrated tilting aid for effortlessly negotiating obstacles such as steps and kerbs. Push handles for simple transport and manoeuvrability.
