Kärcher professional high-pressure cleaner with grey body and large wheels, featuring a mounted spray lance.

Awards and exclusive range

High-pressure cleaner

HDS-E 8/16-4 M 24 kW

This device requires instruction

Order number: 1.030-904.0

Economical eco!efficiency mode
Tilting aid
Two cleaning agent tanks with automatic rinsing

Technical data

Number of current phases (Ph)	3
Voltage (V)	400
Frequency (Hz)	50
Flow rate (l/h)	300 - 760
Working pressure (bar / MPa)	30 - 160 / 3 - 16
Temperature (for supply 12 °C) (°C)	min. 45 - max. 85
Connected load (kW)	29.5
Power cable (m)	5
Heating output (kW)	24
Weight (with accessories) (kg)	122.1
Weight incl. packaging (kg)	133.8
Dimensions (L × W × H) (mm)	1330 x 750 x 1060

Scope of supply

Spray gun, EASY!Force Advanced
High-pressure hose length, 10 m
High-pressure hose specification, DN 6, 250 bar
Spray lance, 1050 mm
Power nozzle

Equipment

Exhaust-free electric heating
Control bar with display light
Pressure cut-off
2 Detergent tanks
Servo Control

Recommended maximum duration of use in hours/day.

Regulierung von Druck und Wassermenge an der Pistole.

High-pressure trigger gun with zero holding force for fatigue-free operation.

Schlauch mit frei drehbar gelagerten Anschlüssen.

Robust, long-lasting quick-release lock: five times faster than screwing.

Switchable cleaning agent dosing system with quick-change function.

Product information and benefits

Economical yet enormously powerful: the innovative HDS E 8/16-4 M hot water high-pressure cleaner offers a 24 kW heating output and a high work temperature of maximum 85°C. It is also extremely economical. The innovative, highly effective boiler insulation of the electrically heated machine reduces the power consumption in stand-by mode by a full 40%. When the Eco!Mode is activated, the high-pressure cleaner automatically switches to highly economical 60°C operation, which is entirely sufficient for most cleaning tasks. If, however, very oily and greasy dirt needs to be removed, the maximum possible work temperature is worth using. With Servo Control, it is easy to maintain a temperature of up to 70°C, even in continuous operation. Additional innovative details such as the EASY!Force high-pressure gun, which makes use of the recoil force of the high-pressure jetto reduce the holding force for the operator to zero, as well as the EASY!Lock quick-release fasteners, which make set-up and dismantling five times faster than with conventional screw connections, round off the outstanding equipment package.

Reduced operating costs

Highly effective insulating material saves up to 40% energy in stand-by mode. Economical Eco!Mode.

HDS E easyforce engine shed app ant 4 CI15502x502 1

Particularly high work temperature

Large water reservoir (max. 85°C). Up to 45°C in continuous operation under full load or 70°C with Servo Control.

Save time and energy: EASY!Force high-pressure gun and EASY!Lock quick-release fasteners

Fatigue-free work at last: the EASY!Force high pressure gun. Robust EASY!Lock quick-release couplings: five times faster than screws.
