Yellow and black Kärcher submersible pump with a handle and attached float switch, set against a white background.

Submersible dirty water pump

SP 11.000 Dirt

Order number: 1.645-820.0

Max. flow rate < 11,000 l/h, delivery height 7 m, pressure up to max. 0.7 bar
Ceramic slide ring sealing, float switch, Quick Connect adapter
Hose connection piece

Show full label

Technical data

Rated input power (W)	400
Max. flow rate (l/h)	11000
Delivery temperature (°C)	35
Delivery head (m)	7
Pressure (bar)	max. 0.7
Grain size (mm)	20
Immersion depth (m)	7
Min. residual water, manual (mm)	25
Residual water height (mm)	25
Connection thread	G1 1/2
Pressure-side connection thread	G1/2 internal thread
Power cable (m)	10
Voltage (V)	230 - 240
Frequency (Hz)	50
Colour	Yellow
Weight without accessories (kg)	4.4
Weight incl. packaging (kg)	5.2
Dimensions (L × W × H) (mm)	229 x 238 x 303

Scope of supply

Hose connection piece, G1, 1”, 1 1/4”, 1 1/2”

Equipment

Comfortable carrying handle
Easy hose connection thanks to Quick Connect
Switching between manual/automatic operation: Possibility of fixing the float switch
Float switch
In automatic operation (auto), the pump automatically switches with the water level
In manual operation, the pump runs continuously to ensure the minimum quantity of residual water
Ceramic face seal.

eye catcher 5 years guarantee oth 5 EN CI15 1

Product information and benefits

The Kärcher SP 11.000 Dirt submersible dirty water pump transfers up to 11,000 liters of clean or dirty water—containing particles up to 20 mm in size—per hour from rain barrels or ponds. An optional prefilter protects the pump impeller in cases of heavy soiling. The float switch controls automatic switching on and off based on the water level and protects the unit against dry running. By securing the float switch, the pump can be operated manually down to a residual water level of 25 mm. The unit is equipped with a slide ring sealing. The Quick Connect connection port is designed for 1", 1 1/4", and 1 1/2" hoses. Registering via the Home & Garden app allows for a warranty extension to 5 years.

Ceramic face seal.

For an extra long lifetime.

Float switch

Switches the pump on and off again according to the water level, preventing dry running.

Quick Connect

Connection thread for quickly and simply connecting 1″, 1 1/4″ and 1 1/2″ hoses or a G1 connection.

Designed for dirty water

Reliable pumping of water with dirt particles up to 20 mm in size.

Possibility of fixing the float switch

For switching to continuous operation.

Comfortable carrying handle

Comfortable to hold and can also be used as a rope holder.

Sturdy and easy to attach prefilter as accessory

Protects the pump against excessively heavy soiling and thus prevents the pump impeller from becoming blocked.
