Yellow Kärcher wet and dry vacuum cleaner with hose, nozzle, filter, and dust bag on white background.

Awards and exclusive range

Wet and dry vacuum cleaner

WD 3 – 17L

Part number: 1.628-103.0

Streamline your DIY projects with integrated storage and blower function.
Includes specialised one-piece cartridge filter and accessories for tough workshop mess.

Technical data

Rated input power (W)	1000
Suction Power (W)	230
Vacuum (mbar)	230
Air flow (l/s)	45
Container capacity (l)	17
Container material	Plastic
Power Cable (m)	4
Standard accessory ID (mm)	35
Voltage (V)	220 - 240
Frequency (Hz)	50 - 60
Sound pressure level (dB(A))	74
Colour	Yellow
Weight without accessories (kg)	4.5
Weight incl. packaging (kg)	7.2
Dimensions (L × W × H) (mm)	349 x 328 x 492

Scope of supply

Suction hose length: 2 m
Suction hose type
Suction hose material
Removable handle
Quantity of suction tubes: 2 Piece(s)
Suction tubes length: 0.5 m
Suction tubes nominal width: 35 mm
Suction tubes material
Wet and dry floor nozzle
Crevice nozzle

Equipment

Cartridge filter: Cellulose
Fleece filter bag: 3-layer
Rotary switch (On/Off)
Blower function
Intermediate parking position of the handle on the device head
Hose storage on the device head
Additional accessory storage on the device head
Storage space for small parts
Folding carrying handle
Cable hook
Parking position
Accessory storage on the device
Sturdy bumper

Product information and benefits

The Kärcher WD 3 is the superior choice for tough jobs around the home that could damage a standard vacuum. Whether you are clearing up after a plumbing leak, vacuuming DIY debris, or cleaning the garage, the 1000W motor produces 230W of suction power to ensure the mess is cleared the first time. The specialised one-piece cartridge filter protects the motor from fine dust and moisture, while the internal float valve automatically cuts off suction when the 17L tank is full. To maintain peak performance, always use a fleece filter bag for dry tasks; explicitly remove the fleece filter bag for all liquid pickup.

Cartridge filter

Switch between wet and dry tasks without stopping to change filters. One-piece filter design allows for quick installation and removal by turning.

Extra-Long Reach with a 10.2m total working radius from the 8m cable and 2.2m hose

Integrated accessory storage ensures tools are kept secure on the 7L container. Combines an 8m cable, 2.2m hose for a wide cleaning reach.

Hose storage on the device head

Secure and space-saving hose storage for both left- and right-handed users. Intuitive securing mechanisms designed for convenient handling during transport.

Integrated storage shelf for safely storing tools and small parts like screws.

Safe, integrated storage on the machine head for small DIY parts and tools.

Versatile Blower Function effortlessly dislodges debris from gravel beds and tight corners

The blower function helps gather scattered debris into one place for quick pickup. Effortlessly dislodge debris from gravel beds and tight areas where suction alone fails.

Fleece filter bag

Extra-durable, triple-layered fleece ensures high dust retention for tough tasks. ‘Steel Ball’ tested to guarantee consistent pickup without motor fatigue.

Quickly park the handle on the device head for stoppages and interruptions.

Handle-parking feature for quick stoppages during secondary cleaning tasks.

280AW of suction power delivers the performance your standard indoor kit is missing.

Clears the heavy-duty mess and liquid spills that would damage indoor cleaners. Ultimate secondary cleaning essential for large-scale projects and renovations.

Awards and exclusive range

WD 3 – 17L

Technical data

Product information and benefits

Cartridge filter

Extra-Long Reach with a 10.2m total working radius from the 8m cable and 2.2m hose

Hose storage on the device head

Integrated storage shelf for safely storing tools and small parts like screws.

Versatile Blower Function effortlessly dislodges debris from gravel beds and tight corners

Fleece filter bag

Quickly park the handle on the device head for stoppages and interruptions.

280AW of suction power delivers the performance your standard indoor kit is missing.

Pull & Push locking system for easy opening of the impact-resistant container.

Ergonomically shaped carrying handle for easy transport to the car or shed.
