Industrial vacuum

IVR-L 200/24-2 Tc Dp

This device requires instruction

Part number: 9.989-404.0

IVR-L 200/24-2 Tc Dp AC-powered liquid and swarf vacuum for vacuuming large quantities of oil and swarf. Maintenance-friendly, robust design.

Make an enquiry

Technical data

Air flow (l/s / m³/h)	148 / 532
Power supply (Ph / V / Hz)	1 / 220 - 240 / 50 - 60
Vacuum (mbar / kPa)	230 / 23
Rated input power (kW)	2.4
Vacuuming type	Electric
Container capacity (l)	200
Filter area for main filter (m²)	0.45
Weight (with accessories) (kg)	131
Weight without accessories (kg)	131
Main filter dust class	L
Dimensions (L × W × H) (mm)	1485 x 760 x 1550
Weight incl. packaging (kg)	131

Equipment

Barrel pump function

Recommended maximum duration of use in hours/day.

Product information and benefits

A powerful two-turbine solution with a rated input power of 2.4 kW makes the IVR-L 200/24-2 Tc Dp AC-powered liquid and swarf vacuum perfect for vacuuming large quantities of oil, as well as cooling emulsions and swarf. The durable pocket filter used with welded seams is washable and keeps the mobile vacuum's suction power constantly high, while a optional strainer basket effectively separates liquid and solid suction media. The emptying system with a tilting chassis enables safe emptying by tilting using minimal force with a roll-off mechanism. It is also possible to use a forklift for emptying. Liquids are drained from the 200 l container by simply detaching the drain hose with a filling level indicator. The integrated, continuously adjustable barrel pump makes it possible to significantly speed up the liquid draining process up to a height difference of 6 metres. Low operating noise is guaranteed by a sound-damped drive unit and the effective exhaust silencer.

Ergonomic tilting chassis

Sophisticated system for safe, manual, effortless emptying. Frame system enables ergonomic tilted emptying using the roll-off mechanism. Quick and convenient emptying of the large 200-litre containers by tilting.

Barrel pump function

An autonomous barrel pump significantly increases the ability for vacuumed matter to be returned. Transparent hose for checking the amount of fluid absorbed.

High robustness, flexibility and modularity

Machine and chassis very robust and equipped with high wall thicknesses. Rotatable hose connection with up to 360° rotatable pipe bend. Optionally available with overfill protection, strainer or accessories holder.

Fitted with two very quiet fan motors

For powerful suction power and optimum cleaning performance. Fans can be switched on separately for individual suction power as required. Very quiet drive head ensures that the cooling air is blown out evenly.

IVR-L 200/24-2 Tc Dp

Technical data

Product information and benefits

Ergonomic tilting chassis

Barrel pump function

High robustness, flexibility and modularity

Fitted with two very quiet fan motors

Equipped with compact surface filter of dust class L
