Kärcher high-pressure cleaner with wheels, hose, and handle, standing upright on a white background.

Awards and exclusive range

High pressure cleaner

HD 5/12 C Plus

Part number: 1.520-903.0

Automatic pressure relief
For horizontal and vertical operation
Save time and energy: EASY!Force high-pressure gun and EASY!Lock quick-release fasteners

Technical data

Number of current phases (Ph)	1
Voltage (V)	230
Frequency (Hz)	50
Flow Rate (l/h)	500
Water feed temperature (°C)	up to 60
Operating pressure ( / MPa)	120 / 12
Max. Pressure (bar / MPa)	175 / 17.5
Power rating (kW)	2.5
Power cable (m)	5
Nozzle size (mm)	35
Water feed	3/4″
Colour	anthracite
Weight (with accessories) (kg)	24.6
Weight incl. packaging (kg)	27
Dimensions (L × W × H) (mm)	380 x 360 x 930

Scope of supply

Trigger gun
High-pressure hose length: 10 m
High-pressure hose specification
Spray lance: 840 mm
Dirt Blaster spray lance

Equipment

Cleaning agent function: Suction
Pressure switch control

Recommended maximum duration of use in hours/day.

High-pressure trigger gun with zero holding force for fatigue-free operation.

Robust, long-lasting quick-release lock: five times faster than screwing.

Product information and benefits

The new HD 5/12 C Plus from Kärcher features a host of benefits to make cleaning jobs that little bit quicker and easier. Typical Kärcher design features add convenience without compromising performance: like the on-board storage for nozzles, power cable, hose and lance; the new carry handle that makes the machines truly portable; and of course the unique lie-flat or stand up operating position.

Save time and energy: EASY!Force high-pressure gun and EASY!Lock quick-release fasteners

Fatigue-free work at last: the EASY!Force high pressure gun. EASY!Lock quick-release locks: durable and robust. And five times faster than a standard screw connection.

Mobility

The integrated carrying handle on the front of the machine enableseasy loading and convenient transport. Push handle can be retracted at the push of a button. Compact package.

Flexibility

Vertical and horizontal operation possible. The wheels are not on in horizontal operation. In this way,the machine offers maximum stability. Separate parking and transport position for the spray unit.

Quality

The automatic pressure relief protects the components and extends the service life. High-quality brass cylinder head. Large, easily accessible water fine filter for protecting the pump against dirt particles in water.

Accessory storage

Screw connection (M 18 × 1.5) for storing a Surface Cleaner directly on the machine. Practical nozzle compartments for triple nozzle and rotary nozzle. Rubber band for attaching the HP hose.
