Dry ice blaster

IB 7/40 Advanced (240V)

Name: IB 7/40 Advanced (240V)
Brand: Kärcher
SKU: 1.574-002.0
Rating: 5.0 (1 reviews)

This device requires instruction

Part number: 1.574-002.0

Operation by the trigger gun
Oil and water separator
For in-house compressed air networks

Make an enquiry

Technical data

Power rating (kW)	0.6
Compressed-air connection	Claw Coupling (DIN3238)
Housing/Frame	Stainless steel (1.4301)
Cable length (m)	7
Air pressure (bar / MPa)	2 - 10 / 0.2 - 1
Quality of air	Dry & oil-free
Air flow (m³/min)	0.5 - 3.5
Sound pressure level (dB(A))	99
Dry ice capacity (kg)	15
Dry ice pellets (diameter) (mm)	3
Dry ice consumption (kg/h)	15 - 50
Number of current phases (Ph)	1
Frequency (Hz)	50 - 60
Voltage (V)	220 - 240
Weight without accessories (kg)	78
Weight (with accessories) (kg)	81.6
Dimensions (L × W × H) (mm)	768 x 510 x 1096

Scope of supply

Grease for nozzle threads
Flat jet nozzle
Flat wrench (for nozzle change), 2 Piece(s)
Blasting hose with electrical control wire and quick couplers
Blasting gun (ergonomic & save)
Tool bag

Equipment

Ice quantity adjusted on the jet gun itself
Air pressure set on the jet gun itself
Switch for "air only" or "ice and air"
Electronic control unit
With integrated earth wire rewinder
Oil and water separator

Product information and benefits

The compact IB 7/40 ice blasting machine offers many of the benefits of the larger IB 15/120 machine but can run from a much smaller compressed air supply, therefore making it ideal for use with in-house compressed air systems. Kärcher’s dry ice blasting technology is a non aggressive but thorough method of cleaning tools, moulds, surfaces and machines with a minimum of downtime. The dry ice pellets are injected into a jet of compressed air, accelerated to speeds in excess of 150 m/s and the fired at the surface to be cleaned. The abrupt cooling of the surface causes a thermal shock and produces fine cracks in the top layer. The dry ice penetrates these cracks, lifts the contaminant from the surface and returns to the atmosphere as CO2 gas leaving only the contaminant behind. Ice blasting uses no chemicals, leaves no wastewater, is environmentally friendly and can be used in areas where cleaning with water is prohibited or inconvenient.

Clear display

Clear indication of adjusted values; easy operation thanks to large buttons and electronic control.

Automatic residual ice emptying

Residual ice tank emptying at the push of button prevents the machine from freezing up on completion of work.

With integrated oil and water separator

No icing up of the device.

Integrated ground strap coil

Easy earthing of the jet object. Protection against flash-over from the user to the object. Improved jet comfort.

Efficient air flow in the machine

The dry ice is transported from the machine to the nozzle without damaging it. Maximum cleaning performance with the nozzle.

Outstanding mobility

Optimum machine balancing for manoeuvring over uneven ground comfortably. Handles at the front and rear of the machine make it easy to carry on stairs.

GRP dry ice container

Optimum isolation of the dry ice. No condensation formation. The machine does not freeze.

Sophisticated trigger gun holder

The trigger gun is always stored securely. Ideal positioning (for removing the nozzles, for example).

IB 7/40 Advanced (240V)

Technical data

Product information and benefits

Clear display

Automatic residual ice emptying

With integrated oil and water separator

Integrated ground strap coil

Efficient air flow in the machine

Outstanding mobility

GRP dry ice container

Sophisticated trigger gun holder

Integrated storage compartment for nozzles and tools
