Kärcher stationary high-pressure cleaner with grey casing and yellow control dials on the front panel.

Awards and exclusive range

High pressure cleaner

HD 8/18-4 St

Name: HD 8/18-4 St
Brand: Kärcher
SKU: 1.524-962.0
Rating: 0.0 (0 reviews)

This device requires instruction

Part number: 1.524-962.0

4-pole water-cooled motor and crankshaft pump with ceramic piston
Easy installation, operation and maintenance of the machine

Make an enquiry

Technical data

Number of current phases (Ph)	3
Voltage (V)	400
Frequency (Hz)	50
Flow Rate (l/h)	500 - 800
Operating pressure (bar / MPa)	180 / 18
Max. Pressure (bar / MPa)	240 / 24
Water feed temperature (°C)	60
Power rating (kW)	5.5
Fuse protection (A)	16
Power cable (m)	5
Water inlet	1″
Mobility	stationary
Weight (with accessories) (kg)	68
Weight incl. packaging (kg)	77.8
Dimensions (L × W × H) (mm)	800 x 605 x 600

Scope of supply

Servo Control
Power nozzle
Frame and cover, Steel, powder-coated
Prepared for Servo Control
Pre-equipped for a detergent inlet

Equipment

Crankshaft pump with ceramic pistons
Dry running protection
Large fine mesh water filter
Storage tank with float valve
Prepared for remote operation
RM1 dosage
Sight glass for oil level
Oil dipstick
Water-cooled motor

Recommended maximum duration of use in hours/day.

Trigger gun regulation of pressure and water flow.

Robust, long-lasting quick-release lock: five times faster than screwing.

Switchable cleaning agent dosing system.

Product information and benefits

Our cold water high-pressure cleaner for stationary continuous operation can be operated with a water inlet temperature of up to 60°C. With an operating pressure of 180 bar and a flow rate of 800 l/h it is suitable for cleaning machinery or production facilities. The unit is equipped with a crankshaft pump featuring a brass cylinder head and a 4-pole, slow-running electric motor. The housing and frame are constructed from powder-coated steel. The machine includes a detergent suction system with a dosing valve and low-level indicator, as well as a water supply tank with dry-run protection and level indicator. Electronic monitoring with displays for errors and maintenance intervals supports safe operation. Control is provided via a large rotary switch; the design is tailored for straightforward installation and maintenance. Accessories such as operating hours counters, remote controls, or automatic pressure relief are not included in the scope of delivery and can be added individually depending on the point of use.

Designed for continuous operation in commercial and industrial use.

4-pole water-cooled electric motor. Crankshaft pump with brass cylinder head and ceramic piston Reliable and powerful: The Kärcher crankshaft pump delivers optimal pressure.

High-quality equipment

Storage tank with float valve and dry-running protection. Frame and cover made of powder-coated steel. Ready for connection of remote controls.

Easy operation

Just one rotary switch for all functions guarantees simple operation without long training times. Practical error display informs users immediately and saves time. Self-explanatory symbols and a clearly-arranged operating field for easy comprehension and increased productivity.

Designed for continuous commercial and industrial use.

Longer working times, less maintenance effort and lower costs. Ideal for industrial use. Designed for daily use. Designed for continuous workflows in commercial and industrial operations.

Cleaning agent suction and dosing system for even better cleaning results

Detergent inlet with valve and empty indicator. Detergent dosing unit on the suction side. Optional: second inlet with valve and empty indicator.

Fine-mesh water filter

Large water fine filter for optimal protection of the pump. Easy to use, easy to clean. Ensures long service life for all high-pressure components.

Electronic monitoring for greater operating safety

Protects the pump against dry running. Switches off in case of leaks or phase failure. Overvoltage and undervoltage protection.

Indicator: error codes, operating status, maintenance intervals

Easy access to all service and maintenance components. Comprehensive service network with highly trained service technicians.

Is ready for use quickly at any time

Ready at the push of a button, with no set-up times or transporting mobile machines. The pump starts when the gun is operated. This enables easy working from any extraction point. The machine is always ready to go for maximum productivity and flexibility.

Always flexible thanks to fast retrofitting capability

A time counter and pressure gauge as well as automatic pressure relief to protect accessories and pipelines are available as options. A second detergent inlet with empty indicator and dosing valve is available as an option. The machine can alternatively be controlled with a remote control.

Product safety and documents

Applications and videos

Application areas

For cleaning machines and vehicles
Agriculture
Versatile applications in industrial settings, e.g. for cleaning production facilities
Ideal for car workshops, vehicle rental stores, car wash centers, building service contractors, trade professionals, small construction companies, small garages and farms, etc.
Industry
Perfect for use in vehicle cleaning, in the construction and transport sectors, as well as industry
Cleaning animal stables in agriculture
For cleaning tasks in the food and chemicals industries
Ideal for car dealerships, car hire companies and service stations
Public Services
