Kärcher industrial dust extractor with flexible hose and metal arm, mounted on wheels.

Industrial deduster

IVR ID 130/22 with arm

Name: IVR ID 130/22 with arm
Brand: Kärcher
SKU: 9.990-920.0
Rating: 0.0 (0 reviews)

This device requires instruction

Part number: 9.990-920.0

Ready for immediate use thanks to suction arm
Very quiet IE3 radial fan
170-litre stainless steel collection container

Make an enquiry

Technical data

Product information and benefits

The ID 130/22 dust removal system with arm has a powerful and energy-efficient (IE3) radial compressor for high volume flows, and is also designed for continuous three-shift operation. The three-phase mobile unit with a rated input power of 2.2 kW and dust class M filter system is designed for vacuuming up large quantities of fine swarf, hazardous and general dusts (TLV > 0.1 mg/m³). Thanks to its robust and easy-to-service design, it fulfils key requirements for tough, industrial applications. The extraction arm supports itself with gas springs and has external joints that extend the working radius to a total length of 3 metres. A manual shaking mechanism effectively cleans the long-lasting compact filter, while the set-down trolley allows for the 170-litre container to be emptied easily and ergonomically without removing the drive head. A polyethylene bag with an integrated closing mechanism and pressure compensation hose on the machine guarantees low-dust emptying and safe disposal of the suction waste.

Designed for dust class M for high occupational safety

Dust class M filter engineering for vacuuming hazardous dust.

Simple and safe emptying without removing the drive head

Set-down trolley and rolling container for ergonomic emptying.

Dust-free emptying system for hazardous materials

Dust-free emptying thanks to PE sack with integrated closing mechanism. Simple disposal of dust in a PE sack.

Number of current phases (Ph)	3
Voltage (V)	400
Frequency (Hz)	50
Air flow (l/s / m³/h)	370 / 1329
Vacuum (mbar / kPa)	33 / 3.3
Container capacity (l)	170
Rated input power (kW)	2.2
Vacuuming type	Electric
Filter area (m²)	9
Sound pressure level (dB(A))	75
Main filter dust class	M
Weight without accessories (kg)	182
Weight incl. packaging (kg)	182.6
Dimensions (L × W × H) (mm)	1170 x 780 x 1580
