Yellow and black Kärcher submersible pump with a handle and attached float switch, set against a white background.

Submersible dirty water pump

SP 9.500 Dirt

Name: SP 9.500 Dirt
Brand: Kärcher
SKU: 1.645-801.0
Price: 84.99 EUR
Availability: InStock
Rating: 4.7 (21 reviews)

Part number: 1.645-801.0

Max. flow rate < 9500 l/h, delivery height 6 m, pressure up to max. 0.6 bar
Ceramic slide ring sealing, float switch, Quick Connect adapter
Connecting Hose

Technical data

Rated input power (W)	280
Max. Flow Rate (l/h)	9500
Delivery Temperature (°C)	35
Delivery Head (m)	6
Pressure (bar)	max. 0.6
Grain Size (mm)	20
Depth of Immersion (m)	7
Min. Residual Water, manual (mm)	25
Residual Water Height (mm)	25
Connecting Thread	G1 1/2
Pressure-side connection thread	G1/2 internal thread
Power Cable (m)	10
Voltage (V)	230 - 240
Frequency (Hz)	50
Colour	Yellow
Weight without accessories (kg)	3.8
Weight incl. packaging (kg)	4.5
Dimensions (L × W × H) (mm)	229 x 238 x 303

Scope of supply

Connecting Hose, G1, 1”, 1 1/4”, 1 1/2”

Equipment

Comfortable Carrying Handle
Easy hose connection thanks to Quick Connect
Switching between manual/automatic operation: Possibility of fixing the float switch
Float Switch
In automatic operation (auto), the pump automatically switches with the water level
In manual operation, the pump runs continuously to ensure the minimum quantity of residual water
Ceramic Face Seal

eye catcher 5 years guarantee oth 5 EN CI15 1

Product information and benefits

Its maximum pump capacity of 9,500 litres per hour makes the SP 9.500 Dirt the perfect entry-level model for quickly pumping out and transferring water from water butts and garden ponds. It reliably pumps out clean and dirty water containing dirt particles up to 20 mm in diameter. For heavy dirt, an optional prefilter can be fitted, which protects the pump impeller against blockages caused by branches, for example. The slide ring sealing – a tried-and-tested solution from our Professional range, fitted in all submersible pumps – also guarantees that the pump has an extraordinarily long lifetime. There is also the option to extend the warranty to five years. The submersible dirty water pump is also fitted with a float switch that switches the pump on and off depending on the water level, thereby also preventing dry running. Thanks to the fixing attachment for the float switch, the pump can be used even at a low water level down to a residual water depth of 25 mm. Also practical: The Quick Connect connection thread enables the quick and simple connection of 1", 1 1/4" and 1 1/2" hoses.

Ceramic Face Seal

For an extra long lifetime.

Float Switch

Switches the pump on and off again according to the water level, preventing dry running.

Quick Connect

Connection thread for quickly and simply connecting 1″, 1 1/4″ and 1 1/2″ hoses or a G1 connection.

Designed for dirty water

Reliable pumping of water with dirt particles up to 20 mm in size.

Possibility of fixing the float switch

For switching to continuous operation.

Comfortable Carrying Handle

Comfortable to hold and can also be used as a rope holder.

Sturdy and easy to attach prefilter as accessory

Protects the pump against excessively heavy soiling and thus prevents the pump impeller from becoming blocked.

SP 9.500 Dirt

Technical data

Product information and benefits

Ceramic Face Seal

Float Switch

Quick Connect

Designed for dirty water

Possibility of fixing the float switch

Comfortable Carrying Handle

Sturdy and easy to attach prefilter as accessory
